    1mm Gauge for checking non-accessibility of live parts meets the requirements of IEC 60601

    Ask Lasest Price
    Brand Name : Julixing
    Certification : CNAS Test Report
    Model Number : LX-1N
    Price : Contacts us
    Delivery Time : 15-20 Days
    Payment Terms : T/T,Western Union,MoneyGram,AliExpress
    Supply Ability : 500 Set per month
    • Product Details
    • Company Profile

    1mm Gauge for checking non-accessibility of live parts meets the requirements of IEC 60601

    Basic Introduction:
    1. According to : IEC 60884 Fig 10
    2. The test probe is used for household and similar electrical appliances of necessary protection of against electric shock test apparatus; Gauge for checking non-accessibility of live parts, through shutters, and of live parts of socket-outlets with increased protection.
    Technical Parameters:
    Gauge: 3mm*1mm(wide * thick);
    Diameter: φ1.0mm
    Test probe length: 80mm
    Force: 1N
    Material: The handle is made of nylon, tip is made of hardened steel

    To calibrate the gauge, a push force of 1 N is applied on the steel rigid wire in the direction of its axis:
    the characteristics of the gauge internal spring shall be such that the surface A – A′ is brought practically to the same level as the surface B – B′ when this force is applied.


    Figure 10 – Gauge for checking non-accessibility of live parts, through shutters, and of live parts of socket-outlets with increased protection
