    UL498 2012 Gauge for Plug and Socket

    UL498 2012 Gauge for Plug and Socket

    1. Application:
    This plug and socket test gauge is mainly used to test and inspect whether the structure and size of plugs and sockets conform to UL 498:2012 standards. And the mainly application industries is electronics, electrical appliances, plugs and sockets and other similar areas.
    2. Features:
    Gauge dimensions, tolerances, material, hardness, surface roughness conform to the standards requirements;
    Material hardness is more than 50HRC;Material thermal expansion coefficient is small,dimensions and tolerances is stable and reliable.

    3.Specifications:

    ItemFigure No.DescribeQuantity
    1UL498-2012 Figure 9.1Articulate probe with web stop1
    2UL498-2012 Figure 10.1Probe1
    3UL498-2012 Figure 31.1Flat probe1
    4UL498-2012 Figure 73.1Reference plug1
    5UL498-2012 Figure 73.2Typical test apparatus1
    6UL498-2012 Figure 98.1Improper insertion test blades2
    7UL498-2012 Figure 109.1Test plug2
    8UL498-2012 Figure 109.2Test blade1
    9UL498-2012 Figure 122.1Receptacle test fixture1
    10UL498-2012 Figure 122.3Push out tool1
    11UL498-2012 Figure 122.5Bridge1
    12UL498-2012 Figure 123.1Test pin A1
    13UL498-2012 Figure 123.2Test pin B1
    14UL498-2012 Figure 123.357g ground pin1
    15UL498-2012 Figure 123.4113g ground pin1
    16UL498-2012 Figure 133.2No.14AWG test pin1
    17UL498-2012 Figure 136.1Small test probe1
    18UL498-2012 Figure 165.2Fixture for assembly security test1
    19UL498-2012 Figure SD 5.1Standard grounding pin1
    20UL498-2012 Figure SD 13.1Standard grounding pin1
    21UL498-2012 Figure SD 13.2Over size ground pin1






    Company introduction


    Shenzhen Julixing Instruments Co., Ltd. are specialized in manufacturing special, custom built, test and measuring equipment for products testing as per international norms and offering calibration services and related information. Our products and services are used by research & development establishments, test laboratories, defense establishments, government institutions & manufacturing industries to fulfill the clients' requirements.
    If you require testing equipment to test products such as home appliances, electrical accessories like switches, sockets, connectors, etc. industrial & road lighting luminaires, automobile lighting systems or related categories, we can provide the solutions you need.
